Aptiv (Delphi) 10 Way Black GT 150 Sealed Female Connector
Part #: 100-00352
Attributes
- COLOR: BLACK
- CAVITY COUNT: 10
- SEALED: SEALED
- MANUFACTURER: DELPHI
- FAMILY: GT
- SERIES: 150
Dimensions
- Weight: 12.98 Grams
This connector is used with the accelerator pedal in the 2004-2005 Cadillac CTS-V with LS6 engine.
Mating Connectors
| Part # | Description | Min Qty | Price | Qty | |
|---|---|---|---|---|---|
|
100-00639 | Aptiv (Delphi) 10 Way Black GT 150 Sealed Male Connector | – | $12.00 |
This connector is used in the following assemblies:
| Part # | Description | Min Qty | Price | Qty | |
|---|---|---|---|---|---|
|
100-00624 | Accelerator Pedal Connector Pigtail for LS6 04-05 CTS-V | – | $25.00 | |
|
100-00645 | TAC to Pedal Harness for 04-05 CTS-V | – | $45.00 |
Secondary Locks
| Part # | Description | Min Qty | Price | Qty | |
|---|---|---|---|---|---|
|
100-00353 | Delphi 10 Way PURPLE GT 150 TPA | – | $1.50 | |
|
100-00552 | Delphi PURPLE GT 150 Tether CPA with harness ring | – | $0.75 | |
|
100-00243 | Delphi GRAY GT 150 Axial CPA | – | $0.50 |
Terminals
| Part # | Description | Min Qty | Price | Qty | |
|---|---|---|---|---|---|
|
100-00124 | Aptiv (Delphi) GT 150 Female Sealed Tin (Sn) 22-20 AWG Terminal | 10 | $0.30 | |
|
100-00125 | Aptiv (Delphi) GT 150 Female Sealed Tin (Sn) 18-16 AWG Terminal | 10 | $0.30 |
Cable Seals
| Part # | Description | Min Qty | Price | Qty | |
|---|---|---|---|---|---|
|
100-00190 | Delphi GT 150 Cable Seal WHITE for Cable Diameters 1.90-1.20mm | 10 | $0.28 | |
|
100-00189 | Delphi GT 150 Cable Seal BLUE for Cable Diameters 2.40-1.86mm | 10 | $0.28 |
Plugs
| Part # | Description | Min Qty | Price | Qty | |
|---|---|---|---|---|---|
|
100-00208 | Delphi GT 150 Cavity Plug | 10 | $0.35 |
